The DJI Matrice 4TD is a next-generation enterprise inspection drone built for the most demanding professional missions. Equipped with a quad-sensor payload — wide-angle, medium-tele, thermal, and laser rangefinder — it delivers industrial-grade situational awareness for infrastructure inspection, emergency response, and public safety operations. Fully compatible with DJI Dock 3 for fully autonomous, remote drone-in-a-box deployments.
Quad-Sensor PayloadThermal + Visual + TeleDJI Dock 3 ReadyIP54 RatedEmergency ResponseLaser Rangefinder48MP Wide CameraNIR Auxiliary LightRC Plus 2 CompatibleAutonomous Missions
Built for Missions That Can't Wait
The Matrice 4TD is designed for real-time situational awareness in complex, time-critical environments. Whether you're assessing damage after a disaster, tracking targets in public safety operations, or conducting night-time infrastructure inspections, the M4TD gives your team the data it needs — fast. Its quad-sensor payload eliminates the need for payload swaps, putting thermal, visual, zoom, and ranging data on screen simultaneously.
Quad-Sensor Payload — See Everything at Once
📷
Wide-Angle Camera
✓ 1/1.3" CMOS Sensor
✓ 48 Megapixels
✓ f/1.7 Aperture
✓ ~24mm Equiv. Focal Length
✓ 4K/60fps Video
🔭
Medium Tele Camera
✓ 1/1.3" CMOS Sensor
✓ 48 Megapixels
✓ f/2.8 Aperture
✓ ~70mm Equiv. Focal Length
✓ 4K/60fps Video
🌡️
Thermal Camera
✓ 640×512 IR Resolution
✓ f/1.0 Aperture
✓ ~53mm Equiv. Focal Length
✓ Super-Res: 1280×1024
✓ Radiometric RJPEG
📡
Laser Rangefinder
✓ Precise Distance Measurement
✓ Works in Low Light
✓ Combines with Thermal
✓ Real-Time Target Ranging
✓ NIR Auxiliary Light
Fully Autonomous with DJI Dock 3
Pair the Matrice 4TD with the DJI Dock 3 to unlock truly autonomous, around-the-clock operations with zero pilot on-site. Schedule automated inspection flights, trigger missions remotely, and receive live footage and data without deploying a team. When the mission ends, the M4TD returns, lands, and recharges automatically — ready for the next deployment.
This makes the Matrice 4TD + Dock 3 combination ideal for permanent site monitoring, critical infrastructure surveillance, and rapid emergency response across large areas.
Who Uses the Matrice 4TD?
The M4TD is purpose-built for enterprise operators who need maximum capability in the field:
🏗️ Infrastructure Inspection
Power lines, pipelines, bridges, and cell towers — inspect at speed with thermal and visual data side by side.
🚨 Emergency Response
Law enforcement and search-and-rescue teams use thermal imaging to locate people in darkness, smoke, or dense terrain.
🔒 Public Safety
Perimeter monitoring, crowd management, and rapid incident assessment — all from a safe, remote standpoint.
🌙 Night Operations
The NIR auxiliary light and thermal camera combine to maintain full situational awareness in complete darkness.
⚡ Remote Deployments
With Dock 3 integration, deploy the M4TD from anywhere with a network connection — no pilot on location required.
Full Technical Specifications
| Category |
Specification |
| Max Flight Time |
42 Minutes |
| Max Speed |
23 m/s |
| Video Link Range |
20 km (O4 Enterprise) |
| IP Rating |
IP54 (Dust & Water Resistant) |
| Wide Camera |
48MP, 1/1.3" CMOS, f/1.7, ~24mm equiv |
| Medium Tele Camera |
48MP, 1/1.3" CMOS, f/2.8, ~70mm equiv |
| Thermal Camera |
640×512, f/1.0, ~53mm, Super-Res 1280×1024 |
| Laser Rangefinder |
Integrated with NIR auxiliary light |
| Dock Compatibility |
DJI Dock 3 (fully autonomous) |
| Controller |
RC Plus 2 (standalone operation) |
| Operating Temperature |
-20°C to 50°C |
| GNSS |
GPS+GLONASS+Galileo+BeiDou |
| Obstacle Sensing |
Omnidirectional |
| Video |
4K/60fps (visual cameras) |
| Weight |
~1100g (aircraft only) |
What's in the Box
📦 DJI Matrice 4TD Aircraft
📦 RC Plus 2 Remote Controller
📦 Intelligent Flight Battery (×2)
📦 Battery Charging Hub
📦 Power Adapter & Cable
📦 Propellers (×4 pairs)
📦 Gimbal Protector
📦 Storage Case
📦 Screwdriver
📦 Spare Screws & Hardware
✅
Authorized DJI Dealer
Official US DJI reseller
🚚
Free US Shipping
On all orders, ships fast
🛠️
Expert Support
Pre-sale advice from drone pros
🔒
Secure Checkout
Safe & encrypted payment
Frequently Asked Questions
Does the Matrice 4TD work without DJI Dock 3?
Yes. The M4TD can be operated as a standalone drone using the RC Plus 2 controller, making it fully functional for traditional piloted missions as well as autonomous Dock 3 deployments.
What is the thermal camera resolution?
The thermal camera captures at 640×512 native resolution, with infrared super-resolution processing delivering up to 1280×1024. It also records radiometric RJPEG files for post-flight thermal analysis.
Can the Matrice 4TD fly at night?
Yes. The integrated NIR auxiliary light illuminates scenes invisible to the naked eye, working in combination with the thermal camera to deliver full situational awareness in complete darkness.
Is the Matrice 4TD waterproof?
The M4TD carries an IP54 rating, making it resistant to dust ingress and water splashes from any direction — suitable for operations in light rain and dusty environments.
What video transmission system does it use?
The Matrice 4TD uses DJI's O4 Enterprise video transmission system, providing a stable, encrypted video link at up to 20 km range with low latency.
Can I see thermal and visual footage at the same time?
Yes. The M4TD supports split-screen and picture-in-picture display modes, allowing operators to monitor thermal and visual (or zoom) feeds simultaneously on a single screen.
